Our Manual Pallet Stacker is a cost-effective equipment to help you handling pallets and these materials come with a foot stand in factory, warehouse, shopping center and so on. Features with integral pump, TITANSUHE’s manual pallet stacker is leaking free, no maintenance need.
Model | SYC-1016 | SYC-1025 | SYC-1030 | SYC-1516 | SYC-1525 | SYC-1530 | SYC-2016 | |
Capacity | kg | 1000 | 1000 | 1000 | 1500 | 1500 | 1500 | 2000 |
Load Center | mm | 500 | 500 | 500 | 500 | 500 | 500 | 500 |
Dead Weight | kg | 250 | 290 | 316 | 270 | 310 | 336 | 290 |
Lowered Mast Height | mm | 2086 | 1836 | 2086 | 2086 | 1836 | 2086 | 2086 |
Lifting Height | mm | 1600 | 2500 | 3000 | 1600 | 2500 | 3000 | 1600 |
Overall Height | mm | 2086 | 3000 | 3500 | 2086 | 3000 | 3500 | 2086 |
Fork Lowered Height | mm | 90 | 90 | 90 | 90 | 90 | 90 | 90 |
Overall Length | mm | 1360 | 1360 | 1360 | 1360 | 1360 | 1360 | 1360 |
Overall Width | mm | 765 | 765 | 765 | 765 | 765 | 765 | 765 |
Fork Dimensions | mm | 30x100x1070(forged)/60x142x1070(fix or movable) | ||||||
Distance betwwen fork arms | mm | 550/660 | 550/660 | 550/660 | 550/660 | 550/660 | 550/660 | 550/660 |
Ground Clearance | mm | 25 | 25 | 25 | 25 | 25 | 25 | 25 |
Turning Radius | mm | 1200 | 1200 | 1200 | 1200 | 1200 | 1200 | 1200 |
Lifting Speed with/without load | mm/stroke | 9.5/10.5 | 9.5/10.5 | 9.5/10.5 | 9.5/10.5 | 9.5/10.5 | 9.5/10.5 | 9.5/10.5 |
Falling Speed with/without load | mm/stroke | Manual Control | ||||||
