3 Ton Endless Polyester Round Sling

Structured with a continuous loop, the most advantage of TITANSUHE's 3ton round sling is the choke point can be adjusted, thus always changing the load-bearing point on the endless slings lifting and avoiding concentrating just on one point. This greatly reduces belt wear and increases its service life.

pho
3 ton endless polyester round sling 1

Data Sheet of 3 Ton Endless Polyester Round Sling


Color

Colour Coded according to DIN-EN-1492-1

Working load limit with 1 webbing sling

Working load limit with 2 webbing sling



Straight  lift

Choked  lift

Lift in different angle

Straight lift up to

Choked lift up to

Straight lift

Choked lift



Data Sheet of Endless Polyester Webbing Sling

Data Sheet of Endless Polyester Webbing Sling

0°-7°

7°-45°

45°-60°

Up to 45°

45°- 60°

45°

45°

45°-60°

45°-60°





Data Sheet of Endless Polyester Webbing SlingData Sheet of Endless Polyester Webbing SlingData Sheet of Endless Polyester Webbing SlingData Sheet of Endless Polyester Webbing SlingData Sheet of Endless Polyester Webbing SlingData Sheet of Endless Polyester Webbing SlingData Sheet of Endless Polyester Webbing SlingData Sheet of Endless Polyester Webbing SlingData Sheet of Endless Polyester Webbing Sling

1

0.8

2

1.4

1

0.7

0.5

1.4

1.12

1

0.8

Purple

WLL1T

1000

800

2000

1400

1000

700

500

1400

1120

1000

800

Green

WLL2T

2000

1600

4000

2800

2000

1400

1000

2800

2240

2000

1600

Yellow

WLL3T

3000

2400

6000

4200

3000

2100

1500

4200

3360

3000

2400

Grey

WLL4T

4000

3200

8000

5600

4000

2800

2000

5600

4480

4000

3200

Red

WLL5T

5000

4000

10000

7000

5000

3500

2500

7000

5600

5000

4000

Blown

WLL6T

6000

4800

12000

8400

6000

4200

3000

8400

6720

6000

4800

Blue

WLL8T

8000

6400

16000

11200

8000

5600

4000

11200

8960

8000

6400

Orange

WLL10T

10000

8000

20000

14000

10000

7000

5000

14000

11200

10000

8000

Orange

WLL12T

12000

9600

24000

16800

12000

8400

6000

16800

13440

12000

9600

Orange

WLL15T

15000

12000

30000

21000

15000

10500

7500

21000

16800

15000

12000

Orange

WLL20T

20000

16000

40000

28000

20000

14000

10000

28000

22400

20000

16000

Orange

WLL30T

30000

24000

60000

42000

30000

21000

15000

42000

33600

30000

24000

Orange

WLL50T

50000

40000

100000

70000

50000

35000

25000

70000

56000

50000

40000

Orange

WLL60T

60000

48000

120000

84000

60000

42000

30000

84000

67200

60000

48000

Orange

WLL80T

80000

64000

160000

112000

80000

56000

40000

112000

89600

80000

64000

Orange

WLL100T

100000

80000

200000

140000

100000

70000

50000

140000

112000

100000

80000



Still not find the material handling equipment you need, Contact Titansuhe for custom hoist lifting straps.
