We are a factory with 10 years of experience, providing products including G80 high strength chain, mining chain, American standard chain, DIN series chain and so on. We are able to produce non-standard or special chains according to customers' requirements, with high quality and competitive price.
mm | ±mm | mm | ±mm | mm | mm | kg/m |
2 | 0.2 | 12 | 0.2 | 3.5 | 7.5 | 0.07 |
0.2 | ||||||
3 | 0.2 | 16 | 0.2 | 4.2 | 11 | 0.16 |
0.2 | ||||||
4 | 0.2 | 16 | 0.3 | 5 | 13.7 | 0.32 |
0.2 | ||||||
5 | 0.2 | 18.5 | 0.4 | 6 | 17 | 0.5 |
0.2 | ||||||
6 | 0.2 | 18.5 | 0.4 | 7.2 | 20.2 | 0.8 |
0.2 | ||||||
7 | 0.3 | 22 | 0.4 | 8.4 | 23.8 | 1.1 |
0.2 | ||||||
8 | 0.3 | 24 | 0.4 | 9.6 | 27.2 | 1.4 |
0.2 | ||||||
9 | 0.4 | 27 | 0.5 | 10.8 | 30.6 | 1.8 |
0.3 | ||||||
10 | 0.4 | 28 | 0.5 | 12 | 34 | 2.2 |
0.3 | ||||||
11 | 0.4 | 31 | 0.5 | 13.2 | 37.4 | 2.7 |
0.3 | ||||||
12 | 0.3 | 36 | 0.6 | 14.4 | 40.8 | 3.8 |
0.3 | ||||||
13 | 0.5 | 36 | 0.6 | 15.6 | 44.2 | 3.8 |
0.3 | ||||||
14 | 0.6 | 41 | 0.7 | 16.8 | 47.6 | 4.4 |
0.4 | ||||||
16 | 0.6 | 45 | 0.8 | 19.2 | 54.4 | 5.7 |
0.4 | ||||||
18 | 0.9 | 50 | 0.8 | 21.6 | 61.2 | 7.3 |
0.4 | ||||||
19 | 0.4 | 53 | 0.9 | 22.8 | 64.6 | 8 |
0.4 | ||||||
20 | 1 | 56 | 1 | 24 | 68 | 9 |
0.5 | ||||||
22 | 1.2 | 62 | 1.1 | 26.4 | 75 | 11 |
0.5 | ||||||
23 | 1.2 | 64 | 1.1 | 27.6 | 78.2 | 12 |
0.5 | ||||||
26 | 1.3 | 73 | 1.2 | 31.2 | 88.4 | 15 |
0.6 | ||||||
28 | 1.4 | 78 | 1.3 | 33.8 | 95.2 | 18 |
0.65 | ||||||
30 | 1.5 | 84 | 1.4 | 41 | 102 | 19.5 |
0.7 | ||||||
32 | 1.6 | 90 | 1.5 | 43 | 108.8 | 23 |
0.75 |
